Description

• Manufacturer : Seneca
• Model : Z109REG2
• Type : Converters
• Condition : New

Maritek Solutions can supply new and refurbished parts of Seneca Z109REG2 Converters.

To receive a quote for any Seneca Converters, Kindly email us at sales@mariteksolutions.com.

Technical Data

Input Types:
Current: Up to 20 mA
Voltage: 75 mV to 20 V
RTD: Pt100, Pt500, Pt1000, Ni100
Thermocouples: J, K, R, S, T, B, E, N
Potentiometer and Rheostat

Output Types:
Current: 0-20 mA, 4-20 mA
Voltage: 0-5 V, 0-10 V, 1-5 V, 2-10 V

Power Supply: 9 to 40 VDC, 19 to 28 VAC

Isolation: 1.5 kVAC, 3-way isolation

Configuration: Via dip-switches, PC software, or handheld device

Operating Temperature: -10 to +60 °C

Humidity: 30% to 90% at 40 °C non-condensing
