Kongsberg Remote Controller Unit – RCU 501

Kongsberg Remote Control Unit RCU 501



Application types
• Dynamic Positioning Systems
• Thruster Control / Steering Systems
• Navigation Sensor Integrator
• Integrated Process Control Systems
• Alarm and monitoring Systems
• Safety Systems



Function

• Dual ethernet LAN process networks
• Dual Redundancy Net interface for redundant RCU configuration
• Dual Remote IO process BUS (RBUS)
• 4 general purpose Digital Input channels
• 4 general purpose Digital Output channels
• 32 serial lines for 3rd party interface
• 2 PROFIBUS channels for 3rd party interface
• 2 CANBUS channels for 3rd party interface



Feature
• Single unit topology: SIL 1 compliant
• Dual unit topology: SIL 2 and SIL 3 compliant

• Triple unit topology
• Ex Zone 2 approved
• Compliant to the following protocols:
1. Modbus (Serial and TCP)
2. NMEA 0183
3. PROFIBUS/PROFIsafe
4. CAN/DeviceNet

• Enhanced watchdog with fail-safe function and system status output
• 3rd party vendor specific protocols are available upon request
• Power:
1. Redundant power input with power alarm monitoring
2. Inrush current and over-voltage protection



Benefits
• Extended Built-in Self- Test (BIST) for computer diagnostics and fault identification during start-up and runtime
• Prepared for online remote diagnostics
• Prepared for online firmware upgrade
• Bootable from fi le server or local flash memory
• Easy installation and replacement
1. DIN Rail mounting
2. All connections are pluggable
3. 3-digit address switches


• Hot swap in redundant applications, dual and triple Hot-Standby redundancy, 1oo2 redundancy
• Status LED indication (Normal/Error)
• RoHS compliant



Computer Performance
RCU501 performance is application dependent and governed by process complexity, updating frequency and number of interfaced I/O. Maximum updating frequency is 50 Hz.
• Configuration guidelines:
1.ESD/PSD: max. 800 I/O, F&G: max. 700 I/O both at scan rate: 1 Hz
2. Process/ Automation: max. 2000 I/O, design advice: 1280 I/O both at scan rate: 1 Hz
3.Anti-surge: 3 loops, Scan rate: 50 Hz
4. Dynamic Positioning: Triple redundant DP system combined with Position Mooring. (Scan rate is adapted to signal processing and varies from 1 to 10 Hz).



To receive a quote, Kindly email us at sales@mariteksolutions.com
