Rig Equipments

NOV Single Pointer Indicators GM6A-Series, bracket mount GM6AP-Series, panel mount

NOV Single Pointer Indicators GM6A-Series, bracket mount GM6AP-Series, panel mount

Provides quick, accurate checks on mud pump operation; helps detect washed out drill pipe or bit nozzle problems. • Indicator gauges can be mounted in the weight indicator box, driller’s console or locally on the mud pump. • Full 360° dial calibration for maximum pointer movement; shows the smallest pressure changes. • Fluid filled gauge has large, easy-to-read 6” dial face and high pressure damper adjust. • Rugged E17-152 Diaphragm Protector mounts with 2” NPT sub. • Hose lengths to 50 feet are standard; longer lengths available in some pressure ranges. Standard capacities • 3,000, 5,000, 6,000, 10,000 and 15,000 psi • 210, 350, 420, 700 and 1000 kg/cm2 • 10K, 21K, 42K, 70K, 80K KPa • 21, 35, 42, 70, 100 MPa To receive a quote for NOV Single pointer indicators, Kindly email us at sales@mariteksolutions.com Read More "NOV Single Pointer Indicators GM6A-Series, bracket mount GM6AP-Series, panel mount"

NOV TRU-VUE Unitized Pressure Gauge GM14-Series

NOV TRU-VUE Unitized Pressure Gauge GM14-Series

NOV has the only mud pressure gauge that can be read easily from 75 feet and more away. • Rugged yet precise bourdon tube and movement indicator offers unmatched performance for standpipe and local pressure manifold applications. • Valuable for blowout prevention and cementing, fracturing, acidizing and gravel packing trucks. • Integral adjustable damper for eliminating pointer oscillations. • Fluid filled case for movement lubrication and pointer dampening. To receive a quote for NOV Unitized Pressure Gauge, Kindly email us at sales@mariteksolutions.com Read More "NOV TRU-VUE Unitized Pressure Gauge GM14-Series"

NOV Anchor Type Weight Indicators AWE Series

NOV Anchor Type Weight Indicators AWE Series

The hydraulic deadline anchor type weight indicator is a standard of the industry, and NOV weight indicators set the standards for quality, accuracy, and reliability against which all others are judged. NOV has weight indicator models designed to work in conjunction with all industry-standard deadline anchors using either tension or compression hydraulic load cells. Indicator systems are supplied as either portable box-mount instrument systems or panel mounted as part of a driller’s console. Each system accurately senses tension in the deadline and uses this to indicate hook load and weight on bit. Many models have separate pointers for both hook load and weight on bit. In addition, integral circular hydraulic recorders are also offered on several models. Type 200, AWE-Series • For deadline loads to 200,000 lbs. Type 150, AWE-Series • For deadline loads to 150,000 lbs. Type 125, AWE-Series • For deadline loads to 125,000 lbs. Type EB, AWE-Series • For deadline loads to 100,000 lbs. Type E, AWE-Series • For deadline loads to 75,000 lbs. Type D, AW-Series • For deadline loads to 50,000 lbs. Type FS, AWA-Series • For deadline loads to 40,000 lbs. Type G, AWG-Series • For deadline loads to 30,000 lbs.   To receive a quote for NOV Weight indicators, Kindly email us at sales@mariteksolutions.com Read More "NOV Anchor Type Weight Indicators AWE Series"

Ingersoll Rand PS2-10000H Series Liftstar and Pullstar Hydraulic Winches

Ingersoll Rand PS2-10000H Series Liftstar and Pullstar Hydraulic Winches

Durability Rugged cast iron and steel construction delivers long-life Minimum 18:1 drum diameter to wire rope diameter reduces wire rope wear Safety Lever control allows for precise positioning Built-in handles and compact design make carrying easy (portable) Performance Gearbox-in-drum design reduces size and helps the winch fit in compact applications Hydraulic motors offers high torque and high efficiency at low motor speed Easily configured to meet worldwide standards including ANSI/ASME B30.7 and CE FEM Classification 1 Bm Free spool clutch for rapid rope payout (Pullstar winches) To receive a quote for Ingersoll Rand Winches, Kindly email us at sales@mariteksolutions.com Read More "Ingersoll Rand PS2-10000H Series Liftstar and Pullstar Hydraulic Winches"

Ingersoll Rand PS4000H Series Liftstar and Pullstar Hydraulic Winches

Ingersoll Rand PS4000H Series Liftstar and Pullstar Hydraulic Winches

Durability Rugged cast iron and steel construction delivers long-life Minimum 18:1 drum diameter to wire rope diameter reduces wire rope wear Safety Lever control allows for precise positioning Built-in handles and compact design make carrying easy (portable) Performance Gearbox-in-drum design reduces size and helps the winch fit in compact applications Hydraulic motors offers high torque and high efficiency at low motor speed Easily configured to meet worldwide standards including ANSI/ASME B30.7 and CE FEM Classification 1 Bm Free spool clutch for rapid rope payout (Pullstar winches) To receive a quote for Ingersoll Rand Winches, Kindly email us at sales@mariteksolutions.com Read More "Ingersoll Rand PS4000H Series Liftstar and Pullstar Hydraulic Winches"

Ingersoll Rand LS2000H Series Liftstar and Pullstar Hydraulic Winches

Ingersoll Rand LS2000H Series Liftstar and Pullstar Hydraulic Winches

Durability Rugged cast iron and steel construction delivers long-life Minimum 18:1 drum diameter to wire rope diameter reduces wire rope wear Safety Lever control allows for precise positioning Built-in handles and compact design make carrying easy (portable) Performance Gearbox-in-drum design reduces size and helps the winch fit in compact applications Hydraulic motors offers high torque and high efficiency at low motor speed Easily configured to meet worldwide standards including ANSI/ASME B30.7 and CE FEM Classification 1 Bm Free spool clutch for rapid rope payout (Pullstar winches) To receive a quote for Ingersoll Rand Winches, Kindly email us at sales@mariteksolutions.com Read More "Ingersoll Rand LS2000H Series Liftstar and Pullstar Hydraulic Winches"

Ingersoll Rand PS2-1000H Series Liftstar and Pullstar Hydraulic Winches

Ingersoll Rand PS2-1000H Series Liftstar and Pullstar Hydraulic Winches

Durability Rugged cast iron and steel construction delivers long-life Minimum 18:1 drum diameter to wire rope diameter reduces wire rope wear Safety Lever control allows for precise positioning Built-in handles and compact design make carrying easy (portable) Performance Gearbox-in-drum design reduces size and helps the winch fit in compact applications Hydraulic motors offers high torque and high efficiency at low motor speed Easily configured to meet worldwide standards including ANSI/ASME B30.7 and CE FEM Classification 1 Bm Free spool clutch for rapid rope payout (Pullstar winches) To receive a quote for Ingersoll Rand Winches, Kindly email us at sales@mariteksolutions.com Read More "Ingersoll Rand PS2-1000H Series Liftstar and Pullstar Hydraulic Winches"

Ingersoll Rand LS2-600 Series Liftstar and Pullstar Hydraulic Winches

Ingersoll Rand LS2-600 Series Liftstar and Pullstar Hydraulic Winches

Durability Rugged cast iron and steel construction delivers long-life Minimum 18:1 drum diameter to wire rope diameter reduces wire rope wear Safety Lever control allows for precise positioning Built-in handles and compact design make carrying easy (portable) Performance Gearbox-in-drum design reduces size and helps the winch fit in compact applications Hydraulic motors offers high torque and high efficiency at low motor speed Easily configured to meet worldwide standards including ANSI/ASME B30.7 and CE FEM Classification 1 Bm Free spool clutch for rapid rope payout (Pullstar winches) To receive a quote for Ingersoll Rand Winches, Kindly email us at sales@mariteksolutions.com Read More "Ingersoll Rand LS2-600 Series Liftstar and Pullstar Hydraulic Winches"

Ingersoll Rand LS2150 Hydraulic Offshore Man Rider Winch

Ingersoll Rand LS2150 Hydraulic Offshore Man Rider Winch

Durability Stainless Steel Enclosure protects moving parts from the elements Marine grade paint provides superior corrosion resistance 10:1 Design Factor for extra-long life   Safety Automatic Multi-Disc Brake and Automatic Drum Brake provide the safety of two independent braking systems Slack line prevention system automatically stops the winch from paying out in case of slack wire Built-in limit switches prevents raising or lowering past set limits   Performance Helical Grooved Drum assists with wire rope spooling Press Roller assists with wire rope spooling Designed to meet the latest regulations including CE, ATEX and DNV type approval To receive a quote for Ingersoll Rand Winches, Kindly email us at sales@mariteksolutions.com Read More "Ingersoll Rand LS2150 Hydraulic Offshore Man Rider Winch"

Ingersoll Rand FA2i Mining Air Winch

Ingersoll Rand FA2i Mining Air Winch

Durability Powerful radial piston air motor provides reliable power and adjustable speed Rugged all-steel construction for maximum life Abrasion resistant sheathing over control hoses Sealed, automatic disc brake for sure operation and protection from moisture and contaminants Safety Full debris protection with drum and control guards Remote pendant control with variable speed and quick release/replace Performance 9.4 hp radial piston motor with ample torque and precise spotting control Quick check oil sight gauge on motor Quick release remote pendant control for remote operation To receive a quote for Ingersoll Rand Winches, Kindly email us at sales@mariteksolutions.com Read More "Ingersoll Rand FA2i Mining Air Winch"
